Custom Android 11 Industrial Panel PC Embedded IP65 Capacitive All In One

Place of Origin SHENZHEN
Brand Name PiPO or Your Brand
Certification UL/CE/CCC/ISO
Model Number IPC-002
Minimum Order Quantity 200
Price Contact Us Now,For a Detailed Quotation
Packaging Details Custom Your Idea
Delivery Time 15-65 Days
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 10000 Sets/month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Screen Size 15 Inch/ 15.6 Inch / 17 Inch / 18.5inch / 19 Inch CPU RK3288 / RK3399 / RK3588
Memory 2GB Or 4GB Hard Drive Capacity 32GB Or 64GB
I/O Interface 1xHDMI/VGA/LAN, 4x USB/Audio Out/Power DC Touch Type 10 Points Projective Capacitive Touch Optional
Working Voltage DC 12V Temperature Range Operating: -10 To 60°C, Storage :-20 To 70°C
High Light

Industrial Panel PC Capacitive

,

IP65 Industrial Panel PC

,

Android 11 embedded panel pc

Leave a Message
Product Description

Custom Android Industrial Panel PC Embedded Touch Android 11 Panel PC IP65 Capacitive All In One PC

15 " / 15.6" / 17" / 18.5" / 19"  Embedded inch RK3288/RK3399 Android Touch Panel PC Embedded Android All in one PC

Description
  • Design



01.Adopt aluminum alloy front bezel, true flat design



02.Ture flat screen design, IP66 front waterproof and dustproof



03.Adopt brand industrial LCD/LED panel,high brightness,contrast ratio,wide view angle. High brightness 1000cd/m2~1500cd/m2, sunlight readable optional



04.On board standard Kingston 2GB DDR3, 32GB SSD hard Disk. High configurations optional



05.10 points Projected capacitive touch panel,high sensitive touch experience



06.Support power on, support 7x24 hours of uninterrupted work



07.Built-in speaker, Gigabit Ethernet port, built-in wifi antenna, support for wireless Internet access



08.Support embedded,desk, wall mounted, ect installation way



Product Description



PC specification
CPU
RK3288 28nm Quad core ARM Cortex A17 1.8 GHz
Memory
2GB DDR3
Nand Flash
EMMC Flash 8GB,24 bit ECC
Audio
Realtek ALC662, High Definition Audio (HD), Line in, Line out
Video playback
Support wmv,avi,flv,rm,rmvb,mpeg ,ts,mp4
Image Format
Support BMP,JPEG,PNG,GIF
Network support
3G, Ethernet, WiFi, wireless peripheral expansion
Wireless Network
WIFI optional
I/O Interface
USB ,Lan(RJ45),COM(RS232), SIM /TF slot ,HDMI/Audio OUT/POWER DC,WIFI
Opetation System
Support above Android 4.4-6.1 operation system
LCD panel
Panel size
12.1 Inch
Resolution
1024x768
Brightness (cd/m²)
350 cd/m2
Response time
15ms
Contrast ratio
800:1
View angle
80°/80°/60°/80° (R/L/U/D)
Touch panel
Touch Type
10 points projective Capacitive touch
Touch Interface
USB
Response time
<8ms
Transmittance
75-85%
Power Supply
External Power Supply
AC 100 - 240V
Working voltage
DC 12V
Power consumption
≤18W
Operating Environment
Temperature range
operating: -10 to 60°C, storage :-20 to 70°C
Relative humidity
5%~95% @ 40° C, non-condensing
Vibration
5-500 Hz, 0.026 G²/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis
Packing Details
Accessories
Power adapter, Wifi antenna
Other
Mounting (options)
1) provide wall brackets for wall-mounting, VESA 100×100mm
2) provide Floor standing to support the PC
Certification
CE, FCC,ROHS
Warranty
1 year warranty
 Picture Details

Custom Android 11 Industrial Panel PC Embedded IP65 Capacitive All In One 0

Custom Android 11 Industrial Panel PC Embedded IP65 Capacitive All In One 1Custom Android 11 Industrial Panel PC Embedded IP65 Capacitive All In One 2

APPLICATIONS

Custom Android 11 Industrial Panel PC Embedded IP65 Capacitive All In One 3

Q1: Can you support to design the tablet pc smartphone laptop outlook?
A1:Yes, we can custom ID and MD design with your reference and using scenario description.

Q2: Do you support the product software(SW) development?
A2: Normally we do system and driver level development, Application-level development will be done by Client or 3rd party
software(SW) developer assigned by clients.

Q3: Which OS can you support development?
A3:Yes, we can support tablet PC & smartphone custom OS based on Android OS ,Windows OS ,Linux OS, Ubuntu OS.

Q4: Can you support to remove the battery from tablet PC?
A4:Yes, sure, we can support tablet PC or smartphone removed battery, removed the camera, shipment without the device case, as well as we can support add the POE,USB Type C, DC IN, HDMI interface on the smart device.

Q5: Can you support SKD service?
Q5: Yes, we can support SKD (software kit development) service for customers.

Q6: Do you have any experience with smart home projects?
A6: Yes,we have rich experience with quite a lot smart home iOT cases. Tuya, Google assistant work with Alexa, Zigbee, Zwave, LoRa, etc.
Actually, we have developed a touch screen device which has a broad range of industrial applications. such us
1) Smart home control
2) Smart touch panel for smart appliance
3) Smart OBD diagnostic device for cars, smart display panel for rear seat of the car,
tablet PC with TOF camera for driving monitoring
4) Smart health care devices for doctor and nurse in hospital, smart senior care tablet PC, smart health care for kids
5) Smart display with AI
6) Different size display open frame for smart scooter smart bike and smart treadmill
7) Smart big touch screen for ad players, POS devices for bank and mall.
8) Education tablet PC with keyboard and stylus pen for students
and other ODM projects too numerous to list.

Q7: Can you support customization of accessories for smart devices?
A7:Yes, we can support custom smart cover, docking charging station, charging dock, magnetic back clip, wall mount, stylus pen for smart device.

Q8: Can you provide prototype samples?
A8: Yes, in principle we can provide prototype samples before bulk order. For this we will need detailed requirements and we will then be able to come back to you with the best proposed solution asap.

Q9: What‘s the normal ODM product development time?
A9: Normally, it takes 3-5 months, but it can vary depending on the complexity of the project. Please contact us and provide detailed requirements and we will propose the best solution to you asap.

Q10: How is the ODM device development cost calculated?
A10: Development charge is in 2 parts:
1) Tooling design;
2) PCBA development and hardware tuning.
Cost also depends on the specific project.
Please contact us and provide detailed requirements and we will propose the most cost effective solution to you asap.

Q11: Can we sign MNDA?
A11: Yes, we can sign MNDA.

Q12 How to deal with the intellectual property?
A13: It's joint development between clients and Pretech. The ownership of the intellectual property depends on the agreement between clients and Pretech.

Q13: What's your after-sales service for ODM smart device ? Can you support two year’s or more warranty?
A13: Normally, we provide a 1-year warranty as standard. However, we can support a 2-year warranty or more, if the customer requires. Please contact us and provide detailed requirements and we will propose the most suitable solution to you asap.
